Direct To Fabric Digital Printing

First of all: digital printing is a general term. According to different fabrics, digital printing can be subdivided into sublimation transfer printing, reactive digital printing, acid digital printing, paint digital direct injection printing and other processes. The common feature of digital...
문의 보내기
제품 소개

First of all: digital printing is a general term. According to different fabrics, digital printing can be subdivided into sublimation transfer printing, reactive digital printing, acid digital printing, paint digital direct injection printing and other processes. The common feature of digital printing is inkjet printing. Its technical realization is to precisely spray nano-scale dyes or pigments on the fabric through the nozzle of the printer under the control of the computer, so as to obtain complex patterns and precise pattern cycles. The accuracy of the printer nozzle is a prerequisite for determining the fineness of digital printing products. Therefore, the first thing to consider when choosing a printer is the physical accuracy of the printer nozzle, that is, DPI (dots per inch). The higher the DPI, the higher the accuracy of the printer. So the higher the printing accuracy, the better? Of course not, the precision converted into benefits is the effective precision, and the idle redundant function itself is a waste of resources. In most cases, the printer 720DPI is the normal production precision.









Product mode

YSR1816

Print head

8pcs Ricoh Gen6 print head

Fabric conveyance mode

Adhesive belt with cleaning and heating system

Maximum medium width

1850mm

Production speed

Gen5 E

2 pass:330m2/h

Print software

Neostampa / Texprint

Ink Type

reactive , disperse or acid ink,pigment(8 color)

Power voltage

380V,3L+N+G(with independent reliable effective earth wire)

Power consumption

printer 15kw, electric dyer 20kw(steam dryer 4kw)

Workshop condition

Temperature:20-30℃,humidity:55-65%

Measurement(with wooden case)

Printer

4700*2200*1950mm (L* W* H)

Dryer

2300*2200*1950mm (L* W* H)

Weight

G.W:4800kg N.W.:4200KG
